Table Size ................... 35.43" X 16.14"

Maximum Table Load ........... 1100 LBS.

Table TravelS:

 X - Axis .................... 22.05"

 Y - Axis .................... 16.14"

 Z - Axis .................... 18.11"

Rapid Traverse Rate:

 X & Y AXES .................. 945 IPM

 Z ........................... 709 IPM

Spindle Taper Cat ............ #40

Spindle Speed Range .......... Up To 7000 RPM

Spindle Nose to Table Top .... 5.91"- 24.02"

Tool Magazine ................ 24 ATC

Tool Change Time(Chip To Chip) 5.5 Secs.

Main Motor ................... 15/10 HP AC

Approximate Machine Weight ... 11,000 LBS.



EQUIPPED WITH:

MAZATROL M32B CNC CONVERSATIONAL CONTROL

RIGID TAPPING

TOOL LENGTH MEASUREMENT

ALL AVAILABLE MANUALS

FULL ENCLOSURES (note, high part has been removed, now open on top)
